PG-FP5 CHAPTER 3 SOFTWARE INSTALLATION
R20UT0008EJ0400 Rev. 4.00 Page 25 of 240
Jul 15, 2010
CHAPTER 3 SOFTWARE INSTALLATION
This chapter explains the following items related to installation.
• Obtaining software
• Installation
• Uninstallation
• Updating programming GUI, firmware and FPGA
3.1 Obtaining Software
Download the programming GUI, USB driver, and FP5 parameter file (PR5 file) from the following Renesas Electronics
website.
URLs Japanese version: http://www2.renesas.com/micro/ja/ods/
English version (Except for Europe area): http://www2.renesas.com/micro/en/ods/
→ Click “Version-up Service”.
English version (For Europe area): http://www.renesas.eu/update → Section PG-FP5-EE
<Programming GUI (including USB driver)>
Click “FlashProgrammer” in the Each Development Tool column and then click “FP5_GUI”.
<PR5 file>
Select the microcontroller to be used in the Each Device Series column and select the device name in the Device
Name column; the FP5 parameter file can then be found.
Caution Use of the latest version of software is recommended to assure the FP5 operation.
3.2 Installation
This section explains the installation procedure for the programming GUI, USB driver and parameter file (PR5 file).
Table 3-1. Installation
Installation
Order
Item Method
1
Programming
GUI
Run the downloaded executable file (fp5_gui_vxxx_e.exe) and perform installation,
following the directions on the installer screen.
2 PR5 file
Decompress the downloaded file to any folder. A *.pr5 file is decompressed into any
folder, so copy it to the FP5_PRJ folder where the programming GUI is installed.
3 USB driver
The USB driver must be installed when connecting the FP5 and the host machine via the
USB interface. The USB driver is stored into the driver folder in the folder where the
programming GUI is installed. The USB driver is installed by Plug and Play. For details,
refer to 3.2.2 Installation of USB driver.
<R>
<R>
<R>
To Next Page
