PG-FP5
APPENDIX C ELECTRI
CAL
SPECIFICATIONS OF TARGET INTERFACE
R20UT0008EJ040
0 Rev. 4.00
Page 222 of 240
Jul 15, 2010
C.3.1
CLK output charact
eristics (T
A
= 0 to 40
°
C, C = 0 pF (unloa
ded condition))
Pin name
Symbol
Parameter or Conditions
MIN.
TYP.
MAX.
Unit
t
CKCY
Clock output frequency
1
20
MHz
t
WHCK
High-level
width
10.0
490
ns
t
WL
CK
Low-level
width
10.0
490
ns
t
PLHCK
Rise
time
3.4
16
ns
CLK
t
PHLCK
Fall
time
4.2
12
ns
t
CKCY
t
WL
CK
t
WHCK
t
PLHCK
t
PHLCK
CLK output
221
223
