Integra 3™ Basic Operaon

Research Instruments Ltd
5
Heated Glass Insert Frame
Do not place the Petri dish over the frame of the Heated Glass
Insert as this area is not heated (page 19).
Figure 5-3
Where an ITO Heated Glass Insert is used in conjuncon with a RI
Saturn 3, Saturn 5 or equivalent laser ablaon system, do not re
the laser with the microscope focussed on the ITO glass surface,
as this may damage the ITO coang.
The Heated Glass Insert is fragile and should be handled with
care. Do not apply excessive force to the glass surface.
The following sketch shows the locaon of the frame of the Heated Glass
Insert (the black area).
The Heated Glass Insert is secured in posion using magnets. The insert
can be removed by pushing gently from beneath. When lowering the
insert into posion ensure that the insert is rotated unl the magnets
re-aach the insert securely.
