Secon 5
Integra 3™ Basic Operaon
25
Research Instruments Ltd
5
Pipee Angle
Control
Pipee Rotator
Figure 5-9




Figure 5-10
Figure 5-11

Figure 5-12








Turn the Pipee Angle Control to increase or decrease the angle of the
pipee. The p of the pipee will stay in focus, so the angle can be
changed at any me during a procedure. For example, the pipee can be
set ‘toe down’ for sperm immobilisaon and then straight for injecon.

 Do not place any force on the baseplate as this will aect the
focus. If any step cannot be completed (for example, if the pipee p
is a long way out of focus at step 7), then carry out the inial pipee
set-up procedure as described on the previous pages.
