Research Instruments INTEGRA 3 - Height Indicators and Calibration

Secon 6
Integra 3™ Electronic Control System

Research Instruments Ltd
6

These show the vercal posion of the toolholders, as set by rotang the
Fine Control Levers. If the Fine Control is turned close to the ends of the
range of movement, the display will turn red and the Integra 3 will emit
three short beeps, repeang every 5 seconds.
When commencing a procedure the TDU vercal posion should be
close to the centre of their range of movement. If the TDU needs to be
set away from the centre point in order to bring the pipee into focus
then follow the Inial Pipee Set-up Instrucons on page 21 before
proceeding.

The Height Indicators are factory calibrated. However, they can be
recalibrated as required. If resistance is felt when turning the Fine Control
Lever before the Height Indicator shows that the limit of movement has
been reached then re-calibraon is required.
Touch the  and then the  icon.
Avoid using the system in the posion pictured below, as there
may be insucient movement to complete the procedure.
