Research Instruments INTEGRA 3 - SOS Oil Syringe Usage

Secon 9
Syringes

Research Instruments Ltd
9

The SOS is a screw actuated syringe for the precise transfer and injecon
of spermatozoa. By using oil (which has very low compressibility) to
transfer the movement of the control knob to the specimen, accurate
aspiraon and injecon can be easily achieved.
Control Knob
Oil Filling Port
Locking Knob for Height/Angle Adjustment
Cylinder
Piston
Figure 9-4

 
Piston Stroke 50mm
Maximum Distance Volume 830µl
Volume Displaced Per Turn 8.3µl
Total Fill Volume (including tubing) Approx. 2ml
Weight 1.5kg
Overall Dimensions 260 x 135 x 80mm
