REXROTH IndraDrive C Series User Manual

Rexroth IndraDrive C Electrical Data 6-1
DOK-INDRV*-HCS02.1****-PR02-EN-P
6 Electrical Data
Note: The current and power data below apply when the allowed
motor cable length is complied.
6.1 Power Section– Mains Supply
Designation Symbol Unit HCS02.1E-
W0012
HCS02.1E-
W0028
HCS02.1E-
W0054
HCS02.1E-
W0070
operating mode on the
three-phase mains
allowed
operating mode on the
single-phase mains
allowed
phase rotation no condition for phase rotation
total power factor TPF at
PDC (single-phase)
cosϕ =
1/λ
L
0.4 0.4 0.4 0.4
total power factor TPF at
P
DC
without / with mains
choke
cosϕ =
1/λ
L
0.6 / -- 0.6 / 0.7 0.64 / 0.75 0.56 / 0.76
power factor of fundamental
component DPF P
DC
without / with mains choke
cosϕ
h1
0.97 / -- 0.97 / -- -- / -- -- / --
mains input voltage U
LN
V 1 * AC (200..250) +-10%
3 * AC (200..500) +-10%
mains frequency f
LN
Hz (50 .. 60) +-2
mains input continuous
current at P
DC cont
I
L,cont
A
eff
6131930
nominal inrush current
(depending on mains input
voltage)
I
L trans max (on)
A 1.4 ... 4.3 3.5 ... 10.7 6.3 ... 19.3 9.9 ... 27.5
connected load
at P
DC_cont
; U
LN
= AC400V;
without HNL01.1E
S
LN
kVA 3.5 8.5 11 16
connected load
at P
DC_cont
; U
LN
= AC400V;
with HNL01.1E
S
LN
kVA -- 7.3 13.3 18.5
Fig. 6-1: Data power section– mains supply

REXROTH IndraDrive C Series Specifications

General

Protection Class	IP20
Communication Interfaces	EtherCAT, PROFIBUS, PROFINET, CANopen
Feedback Systems	Incremental Encoders, Absolute Encoders, Resolver
Ambient Temperature	0°C to 45°C
Cooling Method	Natural convection or forced air
Relative Humidity	5% to 85% (non-condensing)
Control Modes	Torque, position
