Bottom (HCS02.1E-W0028)
hcs0028_x3_x5_x6.fh7
X6
X3
X5
1234
XS2
Fig. 6-25: HC02.1E-W0028 power section connections (bottom)
Description of connections:
Connection Page
X3, Mains connection 6-28
X5, Motor connection 6-30
X6, Motor temperature monitoring, motor holding brake 6-32
XS2, Shield connection (motor cable) 6-42
