System Service Mode

D037/D038/D040/D041 9-338 SM Appendix

5803 19 Inverter Sensor Inverter gate open Inverter gate close

5803 20 Duplex Exit Sensor Paper detected No paper detected

5803 21 Duplex Entrance Sensor Paper detected No paper detected

5803 22 ID/MUSIC Sn Shutter HP Sn Shutter open Shutter close

5803 23 HVPS:CB - -

5803 24 HVPS:T - -

5803 25 Right Door Open SW Door close Door open

5803 26 Right Lower Cover OP SW Cover close Cover open

5803 27 Mechanical Counter:Bk Not set Set

5803 28 Mechanical Counter:FC Not set Set

5803 29 Key Counter Set Sensor Set Not set

5803 30 Key Card Set Sensor Set Not set

5803 31 Toner End Sensor: K End Not end

5803 32 Toner End Sensor: C End Not end

5803 33 Toner End Sensor: M End Not end

5803 34 Toner End Sensor: Y End Not end

5803 35 Fusing Entrance Sensor Paper detected No paper detected

5803 36 Fusing Exit Sensor Paper detected No paper detected

5803 37 Paper Exit Sensor Paper detected No paper detected

5803 38 ITB Contact HP Sensor HP (Contact)

Not HP

(not contact)

5803 39 ITB T-Collect Bttl:Set SW Set Not set

5803 40 PCU T-Collect Bttl:Set SW Set Not set

5803 41 PCU T-Collect Bttl Full Sn Full Not full
