System Service Mode

SM Appendix 9-339 D037/D038/D040/D041

Appendix:

SP Mode

Tables

5803 42 Vertical Transport 1 Sn Paper detected No paper detected

5803 43 Vertical Transport 2 Sn Paper detected No paper detected

5803 44 Tray1 Size Detection SW See "Table 1" below.

5803 45 Tray2 Size Detection SW See "Table 1" below.

5803 46 Bypass Size Detection SW See "Table 2" below.

5803 47 Bypass Length Detection Sn Not detect Detected

5803 48 Bypass HP Sensor Not HP HP

5803 49 Tray1 Paper End Sensor Not end End

5803 50 Tray2 Paper End Sensor Not end End

5803 51 Bypass Paper End Sensor Not end End

5803 52 Tray1 Set SW Set Not set

5803 53 Tray2 Set SW Set Not set

5803 54 Interlock SW 1 Door close Door open

5803 55 Interlock SW 2 Door close Door open

5803 56 DIP SW - -

5803 57 BCU Version - -

5803 58 PCU T-Collect Motor Set Not set Set

5803 59 Reserve Fan:LOCK Lock Normal

5803 70 R-Tray Paper Exit Sensor Paper detected

No paper

detected

5803 71 R-Tray Set Sensor Set Not set

5803 72 1-Bin:Transport Sensor Paper detected

No paper

detected

5803 73 1-Bin:Paper Sensor Paper detected No paper
