System Service Mode

D037/D038/D040/D041 9-340 SM Appendix

detected

5803 74 1-Bin Set Detection Set Not set

5803 75 Shift Tray:Half Turn Sn Not HP HP

5803 76 Shift Tray Set Detection Not set Set

5803 77 1T PFU:Size Sensors See "Table 4".

5803 78 1T PFU:Paper Lift Sn Not upper limit Upper limit

5803 79 1T PFU:Paper Height Sn - -

5803 80 1T PFU:Right Cover SW Open Close

5803 81 1T PFU:Set Detection Not set Set

5803 82 1T PFU:Paper End Sn Not end End

5803 83 2T PFU:Upper Size Sns

5803 84 2T PFU:Lower Size Sns

See "Table 4" below.

5803 85 2T PFU:Upper Paper Lift Sn Not upper limit Upper limit

5803 86 2T PFU:Lower Paper Lift Sn Not upper limit Upper limit

5803 87 2T PFU:Upper Paper Height Sn - -

5803 88 2T PFU:Lower Paper Height Sn - -

5803 89 2T PFU:Right Cover SW Open Close

5803 90 2T PFU:Upper PE Sn Not end End

5803 91 2T PFU:Lower PE Sn Not end End

5803 92 2T PFU:V-Transport Sn Paper detected

No paper

detected

5803 94 LD OFF Check:Factory - -

5803 200 Scanner HP Sensor Not HP HP

5803 201 Platen Cover Sensor Open Close
