Ricoh FT9101 - Page 199

C: Cleaning R: Replacement L: Lubrication, greasing A: Check and adjust
Cycle
Item
Every visit As
necessary
200K 400K 600K 800K 1M 1.2M 1.4M 1.6M 1.8M 2M 2.2M 2.4M 2.6M 2.8M 3M Remarks
Development
Developer
R R R R R R R
Entrance seal
C C C C C C C C C C C C C C C C
Blower brush
ID sensor
C C C C C C C C C C C C C C C C
Blower brush
Side seals
C R C C C C C C C C C C C C C C C
Blower brush
Sleeve gears and
idler gear
C C C R C C C
Wipe with dry cloth
Timing belt pulleys
C C C C C C C
Wipe with dry cloth
Air filter
R R R R R R R R R R R R R R R
ID sensor blower
filter
C C
Remove dust
Toner vessel
C C C
Wipe with dry cloth
Cleaning
Scavenging roller
R R R R R
Scavenging blade
R R R R R
Cleaning seals
C R C C C C C C C C C C C C C C C
Blower brush
Inside cleaning unit
C C C C C C C
Wipe with dry cloth
PCC wire
C R C R C R C R C R C R C R C
Water
PPC casing and
end blocks
C C C C C C C C C C C C C C C
Water
Cleaning carrier
R R R R R R R
Air filters
*C R *C C *C C *C l *C C *C C *C R *C
Replace from side to side
Cleaning drive gear
L L L
G-40M
Paper Feed
Pick-up rollers
R R R R R R R
Paper feed rollers
R R R R R R R
Reverse rollers
R R R R R R R
1st tray paper end
sensor
C C C
Blower brush
Paper dust
collecting vessel
C C
Tray drive gears
L L L
Mobil Temp. 78
4-3
