1 AA00 0116 Decal - Operation ADF 1
2 A028 7795 Cover Grip 1
3 A028 7736 Inverter Cover 1
4 A028 7790 Front Cover Hinge 1
5 A028 7750 Left Upper Cover Sheet 2
6 A028 7796 Inverter Cover Bracket 2
7 A028 7798 Antistatic Brush 1
8 A028 7793 Rear Cover Hinge 1
9 A028 7797 Grounding Plate 1
10 A028 7535 Antistatic Brush 1
11 A028 7751 Shielding Sheet - Front Lower Cover 1
12 AA00 0110 Decal - Operation 1
13 A028 7485 Inverter Pressure Roller 10
14 A028 7482 Inverter Guide Plate 1
15 A028 7491 Lower Exit Guide Plate 1
16 A028 7822 Original Stopper 1
17 A028 7821 Original Exit Tray 1
18 A028 7799 Left Lower Cover 1
19 A028 7999 Antistatic Brush 1
20 A028 7760 Paper Feed Cover Bracket 2
21 A028 7758 Paper Feed Cover Guide - B 2
22 A028 7756 Paper Feed Table Cover 1
23 AA00 0113 Decal - Paper Feed Cover 1
24
25 A028 7755 Bracket - Paper Feed Table Cover 1
26 A028 7757 Paper Feed Cover Guide 6
27 5875 2088 Shoulder Screw - M4 2
28 5936 2773 Magnet Holder Shaft 1
29 A028 7358 Magnet Holder Bracket 4
30 5936 2771 Magnet - Invertor Cover 1
31 A112 7781 ADF Rear Cover 1
32 5936 2480 Magnet Catch Ass’y 1
33 5936 1512 Indicator Panel 1
34 A028 7202 Front Cover 1
35 AA00 0112 Decal - Unlock Transport 1
36 AA00 0109 Decal - Original Misfeed 1
37 A028 7216 Feeler Cover 1
38 A112 7761 Original Guide Mylar 4
39 A112 7763 Mylar - 31x15 4
40 A112 7701 Antistatic Brush Bracket 1
41 A112 7702 Antistactic Brush 437mm 1
42 A112 7703 Antistatic Brush Mylar 1
43 A112 7950 Philips Grounding Wire - 140mm 1
101 0314 0060W Philips Pan Head Screw - M4x6
102 0344 0060F Philips Truss Head Screw - M4x6
103 0313 0060W Philips Pan Head Screw - M3x6
104 0324 0100W Philips Sunken Head Screw - M4x10
105 0344 0120F Philips Truss Head Screw - M4x12
106 0324 0140W Philips Sunken Head Screw- M4x14
107 0710 0040W Hexagon Nut - M4
108 0314 0060B Pan Head Screw - M4 x 6
Rev. 6/4/96
34. ADF EXTERIOR (A112)
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
To Next Page
