Item Description Setting Method
3-04 Supply yield/forming (1) Total copies made by the OPC belt,
developer, and cleaning carrier and the
number of used staple are displayed.
* Up to 8 digits are displayed.
* In the duplex mode (single side original
to 2-sided copy and 2-sided to 2-sided),
the count doubles.
(2) There are ON key’s for the OPC belt,
developer, and cleaning carrier forming
modes.
CAUTION:
In the cleaning carrier forming mode, a
black image in A3 size is made on the
OPC 30 times. Next, a blank image is
made 30 times. Then, this cycle is
repeated once more (a total of 120
images are made). To prevent the toner
density of the developer from lowering,
follow the order below:
1) Developer forming
2) OPC forming
3) Cleaning carrier forming
Press [3-04] of the data logging menu.
⇓
Press "OPC/Developer/CL carrier
forming ON key" one by one.
* Clearing data
Press Clear key.
⇓
Select "YES (clear the data)/NO".
3-05 Copier misfeeds Copier misfeeds are accumulated and
displayed by location and type (sensor
ON or OFF check misfeed).
Display items
Location
. Tray 1 feed
. Tray 2 feed
. Tray 3 feed
. Tray 4 (LCT) feed
. Registration
. Pick-off (separation)
. Fusing (fusing exit)
. Sub total (total of the items above)
. Duplex gate (duplex entrance junction)
. Exit gate (eject junction)
. Exit tray
. Horizontal transport 1 (entrance)
. Horizontal transport 2 (exit)
. LCT top (LCT transport)
. Duplex feed
. Total
Misfeed type
. ON (sensor ON check misfeed)
. OFF (sensor OFF check misfeed)
* Up to 4 digits are displayed.
Press [3-05] of the data logging menu.
⇓
Move the page by Next/Prev.
* Clearing data
Press Clear key.
⇓
Select "YES (clear the data)/NO".
3-06 RDH/finisher misfeeds Misfeeds are accumulated and displayed
by location of RDH, SADF, inverter unit,
finisher, and by type.
Display items
Location
. RDH feed (entrance and 1st transport)
. RDH transport (2nd transport and
registration)
. RDH exit (1st and 2nd reverse, and
exit)
. SADF feed (registration)
. SADF exit
. Inverter unit (inverter entrance)
. Finisher
Misfeed type
. ON (sensor ON check misfeed)
. OFF (sensor OFF check misfeed)
* Up to 4 digits are displayed.
Press [3-06] of the data logging menu.
⇓
Move the page by Next/Prev.
* Clearing data
Press Clear key.
⇓
Select "YES (clear the data)/NO".
1 July 1994 Data Logging
7-11
