See Page 22
7. 1ST & 2ND PAPER FEED SECTION (A112)
See Page 26
9. VERTICAL TRANSPORT SECTION 1 (A112)
See Page 30
11. OPTICS SECTION 1 (A112)
See Page 24
8. 3RD PAPER FEED SECTION (A112)
See Page 28
10. VERTICAL TRANSPORT SECTION (A112)
See Page 32
12. OPTICS SECTION 2 (A112)
LOCATION OF UNIT
FT9101 4 Parts Location and List
