See Page 34
13. OPTICS SECTION 3 (A112)
See Page 38
15. OPC SECTION 1 (A112)
See Page 42
17. OPC CLEANING UNIT 1 (A112)
See Page 36
14. MAIN CORONA UNIT (A112)
See Page 40
16. OPC SECTION 2 (A112)
See Page 44
18. OPC CLEANING UNIT 2 (A112)
LOCATION OF UNIT
FT9101 5 Parts Location and List
