19. DEVELOPMENT UNIT 1 (A112)
See Page 50
21. TRANSFER AND SEPERATION (A112)
See Page 54
23. FUSING UNIT 1 (A112)
See Page 48
20. DEVELOPMENT UNIT 2 (A112)
See Page 52
22. CLEANING UNIT (A112)
See Page 56
24. FUSING UNIT 2 (A112)
LOCATION OF UNIT
FT9101 6 Parts Location and List
