Ricoh FT9101 - Page 465

See Page 58
25. DUPLEX & PAPER EXIT SECTION 1 (A112)
See Page 62
27. DUPLEX & PAPER EXIT SECTION 3 (A112)
See Page 66
29. DUPLEX & PAPER EXIT SECTION 5 (A112)
See Page 60
26. DUPLEX & PAPER EXIT SECTION 2 (A112)
See Page 64
28. DUPLEX & PAPER EXIT SECTION 4 (A112)
See Page 68
30. DRIVE SECTION (A112)
LOCATION OF UNIT
FT9101 7 Parts Location and List
