7.7 Print Out
Item Description Setting Method
6 Print out The following data can be printed If the
optional printer and printer connector unit
are installed.
NOTE:
(1) A printer with a standard RS232C
interface is required. Use the printer with
functions as follows:
Mode: Asynchronous
Data format: Start/Stop/Data bit: 1
bit each
Data bit length: 8 bits
Parity permission: With
Parity setting: Even parity
Baud rate setting: 1,200 bps
Connector: 25 pins, D-connector
(2) If a Seiko printer DPU-411 is used,
the dip switch settings are as follows
(note that the setting of DIP02 SW1 is
different from that for the F200. The data
bit length for the F200 is 7 bits, and that
for the F5 is 8 bits):
SW1 to 8 of DIP01:
OFF/OFF/OFF/ON/ON/OFF/ON/ON
SW1 to 6 of DIP02:
ON/OFF/OFF/OFF/ON/ON
Process Control:
Data for service tool 4-01 to 4-03.
Copies:
Data for service tool 3-01 to 3-04.
Misfeeds:
Data for service tool 3-05 and 3-06.
Service Calls:
Data for service tool 3-07.
Operation Time:
Data for service tool 3-08.
System Setup:
Data for user tool no. 2, 3, 4, 6, 7, 8, 10,
service tool 1-01 to 1-08, 2-01 to 2-16,
4-04, 4-05, 5-02, 5-03, 5-07.
All Items:
All data for the above items.
Press [6] of the main menu.
⇓
Select "Process Control/Copies/
Misfeeds/Service Calls/ Operation Time/
System Setup/All Items".
⇓
Press "Start Print".
Print Out 1 July 1994
7-20
