Ricoh FT9101 - Fuse Table

3.2 Fuse Table
Location Specification Connection Part number Notes
DC power supply unit 6.3A/250V CN1-3 11070673 (EU)
11070753 (NA)
AC power source IN
DC power supply unit 4A/250V CN2-2 ---- (EU)
11070751 (NA)
DC 5V OUT
(Each photo-sensor and eraser
drive)
DC power supply unit 6.3A/250V CN3-3 11070673 (EU)
11070753 (NA)
AC power source IN
Flash power supply unit 6.3A/250V (EU)
6A/250V (NA)
CN1-3 11070281 (EU)
---- (NA)
AC power source IN
ADF DC power supply unit 6.3A/250V CN1-3 11070673 (EU)
---- (NA)
AC 100V IN
Paper feed DC power supply unit 4A/250V CN1-3 ---- AC 100V IN
Development DC power supply unit 4A/250V CN1-3 ---- AC 100V IN
DC motor drive board (FU401) 3.15A/250V (EU)
3.15A/125V (NA)
CN406-2 11070355 (EU)
11070354 (NA)
Agitator motor drive
DC motor drive board (FU403) 3.15A/250V (EU)
3.15A/125V (NA)
CN406-1 11070355 (EU)
11070354 (NA)
Toner supply motor drive
DC motor drive board (FU404) 3.15A/250V (EU)
3.15A/125V (NA)
CN406-3 11070355 (EU)
11070354 (NA)
OPC cleaning motor drive
DC motor drive board (FU402) 1A/250V (EU)
1A/125V (NA)
CN406-4 11070452 (EU)
11070386 (NA)
OPC cleaning pressure
solenoid drive
Main/OPC motor drive board 8A/125V CN3-3 11070393 Main motor drive
Main/OPC motor drive board 1.6A/250V (EU)
2A/125V (NA)
CN4-2 ---- (EU)
11070388 (NA)
OPC motor drive
Duplex blower drive board 3.15A/250V (EU)
4A/125V (NA)
CN1-6 11070355 (EU)
11070390 (NA)
Duplex blower drive
Varistor board 3.15A/250V (EU)
3A/250V (NA)
---- 11070672 (EU)
11070596 (NA)
AC power source IN
ADF control board 5A/250V (EU)
5A/125V (NA)
CN104-3 11070752 (EU)
11070391 (NA)
DC 24V IN
Blower control board 3.15A/250V (EU)
4A/125V (NA)
CN1-6 11070355 (EU)
11070390 (NA)
ADF blower drive
LCT control board (FU400) 6.3A/250V CN402-1 11070753 AC 37V IN
LCT control board (FU401) 2A/250V CN409-1 11070748 Magnetic clutch drive
Finisher control PCB 5A/250V CN101-1 11070752 DC 24V IN
Transport drive motor control PCB 3.15A/250V ---- 11070355 Finisher transport motor drive
Inverter control PCB 5A/250V CN175-3
(Not used)
11070752 Not used
Finisher DC power supply PCB 5A/250V CN1-1 11070752 AC 100V IN
Note:
EU -- European version machine, NA -- U.S.A. version machine
1 July 1994 Fuse Table
3-3
