Finisher section
Shift motor
Shift tray lift belt
Shift cam
Exit roller
Shift tray lift motor
Exit drive motor
Upper transport drive belt
Lower transpoort drive belt
Finisher transport drive belt
Finisher transport mtor
Stack feed-out
motor
Jogger drive belt
Jogger motor
Stapler drive
motor
Stapler drive belt
Stack feed-out belt
1 July 1994 Drive Layout Diagram
1-31
