2. SECTIONAL DESCRIPTIONS
2.1 Paper Feed
2.1.1 Main construction
Structural diagram
Upper limit sensor
Horizontal transport unit
Grip rollers
Vertical transport
roller
Registration
sensor
Paper dust
removal roller
Paper dust tray
Pinch roller
Grip roller
Pick-up roller
Paper feed roller
Reverse roller
Registration
roller
Paper width sensor
Paper set sensor
Lower limit sensor
Paper length sensor
1000 sheets
From LCT
1st tray paper end sensor
1000 sheets
500 sheets
1 July 1994
Paper Feed
2-1
