101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0040W Philips Pan Head Screw - M4x4
104 0313 0140B Philips Pan Head Screw - M3x14
105 0314 0060B Philips Pan Head Screw - M4x6
106 0313 0050G Philips Pan Head Screw - M3x5
107 0324 0080W Philips Sunken Head Screw - M4x8
108 0315 0080W Philips Pan Head Screw - M5x8
109 0315 0100W Philips Pan Head Screw - M5x10
110 0315 0120W Philips Pan Head Screw - M5x12
111 0344 0080F Philips Truss Head Screw - M4x8
112 0951 4008W Philips Screw with Flat Washer - M4
113 0720 0060E Retaining Ring - M6
114 1106 0411 Bushing - 11.5mm
115 0805 3040 Ball Bearing - 6x10x3mm
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 15 Parts Location and List
