101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0313 0060W Philips Pan Head Screw - M3x6
105 0951 4006B Philips Screw with Flat Washer - M4
106 0720 0040E Retaining Ring - M4
107 0720 0060E Retaining Ring - M6
108 0805 3307 Ball Bearing - 8x14x4mm
109 0805 3042 Ball Bearing - 6x10x3mm
110 1105 0005 Nylon Clip - 3N
111 0573 0050E Hexagon Headless Set Screw - M3x5
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 23 Parts Location and List
