101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0050W Philips Pan Head Screw - M3x5
103 0314 0080W Philips Pan Head Screw - M4x8
104 0315 0080W Philips Pan Head Screw - M5x8
105 0344 0060F Philips Truss Head Screw - M4x6
106 0314 0060M Philips Pan Head Screw - M4x6
107 0323 0060W Philips Sunken Head Screw - M3x6
108 0951 4006W Philips Screw With Flat Washer - M4
109 0720 0030E Retaining Ring - M3
110 0720 0040E Retaining Ring - M4
111 0720 0060E Retaining Ring - M6
112 0805 3307 Ball Bearing - 8x14x4mm
113 0741 3506 Ball Bearing - 6x12x4 mm
114 0742 3808 Ball Bearing - 8x16
115 0809 0022 Door Catch Magnet
116 0314 0050W Philips Pan Head Screw - M4x5
117 1204 1280 Push Switch
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 27 Parts Location and List
