101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0080M Philips Pan Head Screw - M5x8
104 0344 0080F Philips Truss Head Screw - M4x8
105 0951 4008W Philips Screw with Flat Washer - M4
106 0951 4006W Philips Screw With Flat Washer - M4
107 0951 4010W Philips Screw With Flat Washer - M4
108 0314 0140W Philips Pan Head Screw - M4x14
109 0313 0140B Philips Pan Head Screw - M3x14
110 0594 0140E Socket Bolt - M4x14
111 1105 0197 Wire Saddle
112 1106 0241 Bushing - 6.7mm
113 1204 1319 Microswitch
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 31 Parts Location and List
