* A028 2510 OPC Unit 1
1 A112 5345 OPC Drive Motor 1
2 AB03 0078 Pulley - 15Z 1
3 AD01 6006 Drive Roller 1
4 AW02 0018 Photointerruptor 1
5 AB03 0076 Pulley - 28Z 1
6 AA08 4008 Bearing Case 2
7 AA04 3025 Timing Belt - P3M 67 1
8 AD01 6004 Roller 4
9 A028 2690 Slider Rail Support Stay 1
10 AA07 0006 Slide Rail 1
11 AA14 0204 Unlock Shaft 1
12 5214 1974 Screw - Slider Stopper 1
13 A028 2600 Roller Release Cam 2
14 A028 2601 Roller Release Hook 2
15 A028 2674 Rear Side Plate Stopper 1
16 AA06 0163 Spring 1
17 5403 1910 Spring Anchor - Stopper Lever 1
18 A028 2599 Cleaning Pad Holder 1
19 AA16 0005 Pad - 12x12x496 1
20 A028 2627 Pressure Plate - Development 2
21 A028 2595 Development Unit Stopper Bracket 2
22 A028 2630 Plate Spring 1
23 A028 2555 OPC Belt Unit Frame 1
24 A028 2602 Stopper Bracket Holder 2
25 5442 2752 Bushing - Lower Registration Roller 2
26 A029 4997 Middle Tray Knob 1
27 AG05 1033 Drum Unit Knob 2
28 A028 2679 OPC Belt Unit Guide Holder 1
29 A028 2632 Front Stay 1
30 AA13 2051 Plate Flange 1
31 AA14 3111 Knob Shaft 1
32 A028 2633 Front Stay Fixing Knob 1
33 AG05 0026 OPC Knob 1
34 A028 9510 OPC Belt 1
35 AA12 0026 Antistatic Brush 1
101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0050W Philips Pan Head Screw - M4x5
103 0314 0100W Philips Pan Head Screw - M4x10
104 0951 4006W Philips Screw With Flat Washer - M4
105 0951 4008B Philips Screw With Flat Washer - M4
106 0344 0080F Philips Truss Head Screw - M4x8
107 0344 0060F Philips Truss Head Screw - M4x6
108 0573 0050W Hexagon Headless Set Screw - M3x5
109 0936 0250 Semicircle Key
110 0805 3453 Ball Bearing - 10x26x8mm
111 0805 3429 Ball Bearing - 8x14x4mm
112 0720 0080E Retaining Ring - M8
113 0720 0060E Retaining Ring - M6
114 1105 0197 Wire Saddle
115 1105 0016 Nylon Clip - 4N
Rev. 6/4/96
15. OPC SECTION 1 (A112)
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 39 PartsLocationandList
