101 0314 0050W Philips Pan Head Screw - M4x5
102 0314 0060W Philips Pan Head Screw - M4x6
103 0314 0080W Philips Pan Head Screw - M4x8
104 0951 4006W Philips Screw With Flat Washer - M4
105 0313 0080W Philips Pan Head Screw - M3x8
106 0314 0080M Philips Pan Head Screw - M5x8
107 0314 0100W Philips Pan Head Screw - M4x10
108 0951 3005W Philips Screw with Flat Washer - M3
109 0344 0080F Philips Truss Head Screw - M4x8
110 0805 3429 Ball Bearing - 8x14x4mm
111 0805 3428 Ball Bearing - 8x16x5mm
112 1105 0016 Nylon Clip - 4N
113 1105 0008 Nylon Clip - 2N
115 1105 0196 Harness Clamp
116 1105 0120 Wire Clip
117 0720 0040E Retaining Ring - M4
118 0720 0060E Retaining Ring - M6
119 0804 9029 Nut - M6
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 41 Parts Location and List
