* AD00 4027 T&S Corona Unit 1
* A028 4340 Transport Unit 1
1 5446 9001 Transport Belt - 4pcs/set 1
2 A028 4388 Transport Drive Roller 1
3 A028 4368 Transport Chamber 1
4 AF02 2018 Driven Roller 1
5 AA15 1230 Seal - 20x8x59 2
6 AA15 1231 Seal - 5x44x64 1
7 A028 4369 Transport Guide Plate 1
8 AD00 4027 T&S Corona Unit 1
9 A028 5426 Separation Sensor Harness 1
10 A028 5393 T&S Sensor 1
11 A028 4392 Rear Unlock Lever 1
12 A028 4394 Unlock Hook 2
13 A028 4357 T & S Spring Plate 4
14 A028 4383 Transport Casing 1
15 AD02 2116 Rear End Block 1
16 AA06 0231 Spring 2
17 AD02 2118 Rear End Block Cover 1
18 AD02 3131 T&S Corona Casing 1
19 A028 4436 Adjusting Plate 1
20 A028 4438 Transfer Entrance Seal 1
21 A028 4442 Rear Paper Guide 1
22 A028 4441 Front Paper Guide 1
23 AA06 3128 Spring 2
24 A028 4449 Transfer Adjusting Knob 2
25 5447 2769 Stepped Screw 2
26 AD02 2117 Front End Block Cover 1
27 A028 9003 T&S Corona Wire 1
28 AD02 2115 Front End Block 1
29 AA06 3065 Spring 2
30 AD02 1026 Corona Wire Receptacle 1
31 A028 4448 T/S Corona Wiring 2
32 AB01 3236 Gear - 21Z 1
33 A028 4381 Transport Support Plate 1
34 A028 4840 Fusing Lock Bracket 1
35 A028 4393 Unlock Link Guide 2
36 A028 4395 Unlock Link 2
37 AA06 0149 Spring 2
38 AA14 8083 Link Shaft 2
39 A028 4414 Harness Clamp 1
40 A028 4412 Power Supply Cover 1
41 A028 4411 Power Pack Cover 1
42 AZ32 0021 TD Power Pack 1
43 A028 5425 T&S Harness 1
44 A028 4391 Front Unlock Lever 1
45 A028 4413 Unlock Stopper 1
46 5442 1659 Stepped Screw - M4 1
47 AD02 1027 Corona Wire Receptacle 1
48 A028 4451 Unlock Lever 1
49 A028 4453 Decal - Misfeed Removal C 1
50 A028 4415 Decal - High Voltage 1
51 A028 4378 Rear Shaft - Transport Unit 1
52 A028 4385 Separation Sensor Cover 1
53 AA15 1513 Sensor Seal 1
54 A028 4384 Separation Sensor Ass’y 1
55 A028 4440 Insulating Tape - 13.5x436mm 1
Rev. 6/28/96
21. TRANSFER AND SEPARATION (A112)
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
To Next Page
