Ricoh FT9101 - Page 542

67 A028 6103 Middle Stay 1
68 A028 6136 Driven Roller Grip 1
69 A028 6512 Guide Plate 1
70 AA06 6039 Spring 1
71 AF02 2023 Upper Roller 1
72 AF02 2024 Lower Roller 1
73 A028 6222 Pressure Lever 1
74 AA06 3058 Spring 1
75 AA15 2400 Cushion - 5x7x75 1
76 AA15 2401 Cushion - 5x8x165 1
101 0314 0060W Philips Pan Head Screw - M4x6
102 0951 4010W Philips Screw With Flat Washer - M4
103 0951 4006B Philips Screw with Flat Washer - M4
104 0314 0100W Philips Pan Head Screw - M4x10
105 0951 3006W Philips Screw With Flat Washer - M3
106 0344 0080F Philips Truss Head Screw - M4x8
107 0951 4006W Philips Screw With Flat Washer - M4
108 0720 0030E Retaining Ring - M3
109 0720 0040E Retaining Ring - M4
110 0720 0060E Retaining Ring - M6
111 0805 3058 Ball Bearing - 8x16x4mm
112 0805 3307 Ball Bearing - 8x14x4mm
113 0740 3808 Bearing - 8x16x5mm
114 0805 3042 Ball Bearing - 6x10x3mm
115 0805 3145 Ball Bearing - 6x12x4mm
116 1105 0008 Nylon Clip - 2N
117 1105 0191 Wire Saddle
A
Rev. 6/4/96
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 63 PartsLocationandList
