Ricoh FT9101 - Page 570

1 A028 5112 Blower Control Board (EU) 1
1 A028 5109 Blower Control Board (USA) 1
2 A028 7789 Right Hinge 1
3 A028 7954 Table Right Cushion 1
4 A112 5841 Connector Harness 1
5 A028 5830 PCB Relay Harness 1
6 A422 5270 Photosensor 1
7 A028 7922 Original Table Bracket 4
8 5936 5231 Indicator Board 1
9 A112 7841 Decal - Paper Size 1
10 A028 7850 Upper Left Table - Original 1
11 AA00 0114 Decal - Original Set ADF 1
12 5875 2088 Shoulder Screw - M4 2
13 A028 7852 Left Table 1
14 A028 5860 Paper Size Sensor 1
15 A028 7859 Side Fence Spring 4
16 A028 7864 Side Fence Collar 4
17 A028 7383 Front Side Fence Hook Guide 1
18 A028 7325 Front Fence 1
19 A028 7865 Side Fence Gear 1
20 A028 7857 Front Side Fence Rack 1
21 A028 7863 Side Fence Collar 4
22 A028 7866 Side Fence Shoe 2
23 A028 7384 Rear Side Fence Hook Guide 1
24 A028 7858 Rear Side Fence Rack 1
25 A112 7228 Rear Side Fence 1
26 A028 5820 Interface Harness 1
27 A028 7938 Interface Board Bracket 1
28 A028 5832 Main Harness 1
29 A028 5835 Safety Switch Harness 1
30 A112 5810 Main Control Board - ADF 1
31 A028 7944 PCB Left Bracket 1
32 A028 5817 Insulating Sheet - PWB 1
33 A028 7945 PCB Right Bracket 1
34 A028 7786 Left Positioning Plate 1
35 A028 7812 Paper Feed Cover Spring 1
36 A028 7788 Left Hinge 1
37 A028 7787 Right Positioning Plate 1
38 A028 7317 Rear End Plate Guide 1
39 A028 7907 End Fence Gear 2
40 A028 7963 End Plate Rear Spacer 1
41 A028 7310 End Plate 1
42 AA00 0111 Decal - End Fence 1
43 A028 7908 End Plate Lock Knob 1
44 A112 7906 Friction Pad 1
45 AA00 0115 Decal - End Plate 1
46 A112 7842 Decal - Paper Size 1
47 A028 7316 Front End Plate Guide 1
48 A028 7992 End Plate Front Guide 1
49 A028 7904 End Plate Cushion 2
50 A112 7830 Right Table 1
51 A028 7341 Turn Pressure Spring 1
52 A028 7902 Rear Shaft 1
53 A112 7903 End Plate Stopper 1
54 AA14 3074 Stepped Screw - M4x5 2
55 A028 7312 End Plate Cover 1
56 5875 2088 Shoulder Screw - M4 2
57 A112 7820 Original Length Actuator 1
Rev. 6/4/96
35. ADF FRAME AND ELECTRICAL SECTION (A112)
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 79
Parts Location and List
