72 A028 7574 Air Duct Seal 1
73 5216 4198 Stepped Screw - Guide Plate 1
74 A112 7579 Air Duct 1
75 5875 2088 Shoulder Screw - M4 2
76 A112 7881 Solenoid Bracket 1
77 A112 7885 Solenoid Spring 1
78 A112 7975 Recycle Arm Solenoid Ass’y 1
79 A112 7925 Nozzle Upper Casing 1
80 A112 7805 Spring - Pinch Roller 1
81 A112 7801 Exit Pinch Roller 1
82 A112 7977 Recycle Arm 1
83 A028 7915 Magnetic Catch Plate - 5x10 1
84 A112 7996 Mylar Sheet - Recycle Arm 1
85 A112 7872 Base Plate - Front 1
86 A112 7873 Base Plate - Rear 1
87 A112 7984 Antistatic Brush - 180mm 1
88 A112 7871 Mylar sheet - 183x22.5 1
89 A422 1078 Bushing - 6x12x4mm 4
90 A112 7887 Harness Holder 1
101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0060B Philips Pan Head Screw - M4x6
103 0314 0040W Philips Pan Head Screw - M4x4
104 0313 0040W Philips Pan Head Screw - M3x4
105 0313 0060W Philips Pan Head Screw - M3x6
106 0313 0100W Philips Pan Head Screw - M3x10
107 0313 0120W Philips Pan Head Screw - M3x12
108 0951 3006B Philips Screw with Flat Washer - M3
109 0951 3006W Philips Screw With Flat Washer - M3
110 0951 4006B Philips Screw with Flat Washer - M4
111 0323 0100W Philips Sunken Head Screw - M3 x 10
112 0323 0080W Philips Sunken Head Screw - M3x8
113 0323 0060W Philips Sunken Head Screw - M3x6
114 0720 0040E Retaining Ring - M4
115 0741 3506 Ball Bearing - 6x12x4 mm
116 0574 0040E Hexagon Headless Set Screw - M4x4
117 0574 0050E Hexagon Headless Set Screw - M4x5
118 0710 0050W Hexagon Nut - M5
119 0701 0060G Flat Washer - M6
A
Rev. 6/4/96
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 81 PartsLocationandList
