Ricoh FT9101 - Page 577

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0060B Philips Pan Head Screw - M4x6
103 0314 0040W Philips Pan Head Screw - M4x4
104 0314 0080W Philips Pan Head Screw - M4x8
105 0324 0060W Philips Sunken Head Screw - M4x6
106 0951 4008W Philips Screw with Flat Washer - M4
107 0951 4006B Philips Screw with Flat Washer - M4
108 0951 3006W Philips Screw With Flat Washer - M3
109 0720 0030E Retaining Ring - M3
110 0720 0040E Retaining Ring - M4
111 0574 0050E Hexagon Headless Set Screw - M4x5
112 0573 0030E Hexagon Headless Set Screw - M3x3
113 0741 3905 Ball Bearing - 5x13x14mm
114 1105 0160 Clamp
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 83 Parts Location and List
