Ricoh FT9101 - Page 580

101 0314 0060W Philips Pan Head Screw - M4x6
102 0951 3006B Philips Screw with Flat Washer - M3
103 0951 3006W Philips Screw With Flat Washer - M3
104 0951 3005W Philips Screw with Flat Washer - M3
105 0313 0040W Philips Pan Head Screw - M3x4
106 0951 4006B Philips Screw with Flat Washer - M4
107 0584 0080B Hexagon Bolt - M4x8
108 0720 0040E Retaining Ring - M4
109 0720 0030E Retaining Ring - M3
110 0701 0040B Flat Washer - M4
111 0741 3506 Ball Bearing - 6x12x4 mm
112 0574 0050E Hexagon Headless Set Screw - M4x5
113 0574 0060E Hexagon Headless Set Screw - M4x6
114 0573 0040E Hexagon Headless Set Screw - M3x4
115 1105 0234 Clamp
116 0313 0060M Philips Pan Head Screw - M3x6
117 0741 3505 Ball Bearing - 5x10x4
118 0701 0040W Flat Washer - M4
A
Index
No.
Part No. Description
Q’ty Per
Assembly
Index
No.
Part No. Description
Q’ty Per
Assembly
FT9101 85 Parts Location and List
