PCDU
G065
3-20
SM
3.10.6 ID
SENSOR
1. PCDU
(
☛
3.10.1)
2.
Fusing
unit (
☛
3.14.
1)
3.
Dev
elopment unit (
☛
3.
11.1)
4.
PCDU rail [A] (
!
x 2,
"
x 1)
5.
ID sensor
bracket [B] (
!
x 1,
"
x 1
)
6.
ID sensor [C
] (
!
x 1)
7.
Per
f
orm the ID se
nsor initial setting
with SP3001-2 (
☛
5.
Servic
e Tables)
G065R991.
W
MF
[B]
[C]
[A]
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
87
