FUSING
G065
3-46
SM
3.1.6
HOT ROLLER/PRESSURE ROLLER
1.
Fusing
unit (
☛
3.14.
1)
2.
Fusing
upper an
d lower
cover (
☛
3.14.3, 3.
14.4)
3.
Fusing
lamp. (
☛
3.1
4.4)
4.
Spring
s x 2 [A] (both sides)
5.
Arms x
2 [B] (both sides)
6.
Paw
l bracket [C] (
!
x 4)
G065R902.
W
MF
[A]
[B]
[C]
