6. Fasten the postcard side fences with the screws.
D0CMIC1302
7. Align the end fence and side fences with the paper size to be loaded, and then load the
paper.
8. Carefully slide the paper tray fully in.
9. Specify the paper type and thickness.
page 210 "Specifying Paper Type and Thickness Settings"
When loading paper of a size that is not automatically detected, specify the paper size.
page 208 "Specifying the Paper Size That Is Not Automatically Detected"
page 209 "Specifying a Custom Size Paper Using the Control Panel"
• Replace the postcard side fences after use.
Loading B5 Vertical or Larger Paper in Wide LCT
When loading paper that is B5 JIS or larger, attach the paper supports.
1. Open the front cover of the wide LCT, remove the screws from the postcard side fences,
and then take them out.
D0CMIC1301
