4.T
roubleshooting for Peripheral Units
842
Cover Interposer T
ray
Frequent Double Feeds/ Failure to Feed
Cause
When feeding special types of paper
, or feeding paper under special conditions, problems such as
double-feed or failure to feed may occur when paper is fed using generic settings.
ï‚·
Double feed or failure to feed tends to occur in the following conditions:
ï‚·
Coated paper
ï‚·
Paper with smooth (slippery) surface
ï‚·
High temperature or high humidity
Solution
