4.13 UNIT PHOTODIODE REF 5010-056
Replacement
The Photometer 5010 v5+ has to be dismantled:
• see chapter 5.1 Opening – item 1 and item 3
Unplug the unit photodiode from the mother board RR-120.
Unscrew the two screws attaching the unit photodiode at the optical unit.
Installation
For installation proceed in reverse order.
RIELE BERLIN Photometer 5010 v5+ 4.13.2 10.05.2006
