4.41 TOUCHSCREEN REF 5010-057
Touchscreen with PCB RR-122
PCB RR-122
Touchscreen with PCB RR-122
Cable for backlight illumination of the touchscreen
Touchscreen with PCB RR-122
Connector for flexible cable with safety latch
Flexible cable of J/ST8
Attention
: In case of separating the PCB RR-122
from the touchscreen the flexible cable has to be
removed after opening the safety latch.
