4.41 TOUCHSCREEN REF 5010-057
Touchscreen with PCB RR-122
Connector for flexible cable with safety latch
Flexible cable of J/ST8
Attention
: The safety latch has to be opened in case
of unplugging the flexible cable.
Touchscreen with PCB RR-122
inside of the top case
CLOSE
OPEN
RIELE BERLIN Photometer 5010 V5+ 4.41.3 11.03.2009
