4.41 TOUCHSCREEN REF 5010-057
Mounting parts of the touchscreen:
With the spacer the position of the touchscreen can
be adjusted. The nut has to be unscrewed.
Nut
Spacer
Spring
RIELE BERLIN Photometer 5010 V5+ 4.41.4 11.03.2009
