Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-21
:CURSor:MANual:BY
Syntax
:CURSor:MANual:BY <y>
:CURSor:MANual:BY?
Description
Set or query the vertical position of cursor B in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<y>
Integer
5 to 394
300
Explanation
 The horizontal and vertical positions of the cursor are defined by the pixel coordinate
of the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400).
Wherein, (0,0) is located at the left top corner of the screen and (600,400) is located
at the right bottom corner of the screen. The horizontal pixel range is from 0 to 600
and the vertical pixel range is from 0 to 400.
 When the signal source of manual cursor measurement is LA, Y type cursor is not
required.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:MANual:BY 200 /*Set the vertical position of cursor B to 200*/
:CURSor:MANual:BY? /*The query returns 200*/
:CURSor:MANual:AXValue?
Syntax
:CURSor:MANual:AXValue?
Description
Query the X value of cursor A in the manual cursor measurement mode. The unit depends
on the horizontal unit currently selected.
Return
Format
The query returns the X value of cursor A in scientific notation.
Example
:CURSor:MANual:AXValue? /*The query returns -4.000000e-06*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:TUNit
:CURSor:MANual:AYValue?
Syntax
:CURSor:MANual:AYValue?
Description
Query the Y value of cursor A in the manual cursor measurement mode. The unit depends
on the vertical unit currently selected.
Return
Format
 When the signal source is CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH, the
query returns the Y value of cursor A in scientific notation.
 When the signal source is LA, the query returns the decimal value corresponding to
the sum of the binary weights of D15 bit to D0 bit at cursor A (the value of the
channel that is not turned on is 0 by default).
Example
:CURSor:MANual:AYValue? /*The query returns 2.000000e+00*/
Related
Commands
:CURSor:MANual:AY
:CURSor:MANual:VUNit

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
