RIGOL Chapter 2 Command System
2-22 MSO1000Z/DS1000Z Programming Guide
:CURSor:MANual:BXValue?
Syntax
:CURSor:MANual:BXValue?
Description
Query the X value of cursor B in the manual cursor measurement mode. The unit depends
on the horizontal unit currently selected.
Return
Format
The query returns the X value of cursor B in scientific notation.
Example
:CURSor:MANual:BXValue? /*The query returns 4.000000e-06*/
Related
Commands
:CURSor:MANual:BX
:CURSor:MANual:TUNit
:CURSor:MANual:BYValue?
Syntax
:CURSor:MANual:BYValue?
Description
Query the Y value of cursor B in the manual cursor measurement mode. The unit depends
on the vertical unit currently selected.
Return
Format
 When the signal source is CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH, the
query returns the Y value of cursor B in scientific notation.
 When the signal source is LA, the query returns the decimal value corresponding to
the sum of the binary weights of D15 bit to D0 bit at cursor B (the value of the
channel that is not turned on is 0 by default) .
Example
:CURSor:MANual:BYValue? /*The query returns -2.000000e+00*/
Related
Commands
:CURSor:MANual:BY
:CURSor:MANual:VUNit
:CURSor:MANual:XDELta?
Syntax
:CURSor:MANual:XDELta?
Description
Query the difference between the X values of cursor A and cursor B (BX-AX) in the manual
cursor measurement mode. The unit depends on the horizontal unit currently selected.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:MANual:XDELta? /*The query returns 8.000000e-06*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:BX
:CURSor:MANual:TUNit

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
