Robopac Ecoplat Base - Technical Data (Ecoplat Base - FRD - RS - PPS)

Chapter 2
TECHNICAL INFORMATIONS
- 10 -
English
C224153200.fmIDM
2.7. TECHNICAL DATA (ECOPLAT BASE - FRD - RS - PPS)
L
H
F
E C
B
A
D
N
M
G
IDM-24153201200.pdf
Table 2.1: Technical machine specifications (Ecoplat Base - FRD - RS - PPS)
Description
Unit of
meas-
ure
Ø C (L)
Model
Ecoplat Base
Ecoplat FRD
Ecoplat FRD (for
net)
Ecoplat RS Ecoplat PPS
Overalll dimensions
(A) mm 1500 / 1650 2200 / 2400 1185 1185 1280 1280
(B) mm 1500 / 1650 2200 / 2400 720 720 720 720
(D)
mm 1500 2200 / 2400 2440 2440 2440 2440
mm 1650 2200 / 2400 2590 2590 2590 2590
(E)
mm 1500 2200 / 2400 1575 1575 1670 1670
mm 1650 2200 / 2400 1650 1650 1745 1745
(F) (Standard version) mm 1500 2200 / 2400 73.5 75.5 75.5 75.5
(F) (Optional version)
mm 1500 2200 / 2400 75.5 - - -
mm 1650 2200 / 2400 77.5 77.5 77.5 77.5
(G)
mm 1500 / 1650 2200 2580 2580 2580 2580
mm 1500 / 1650 2400 2780 2780 2780 2780
(H)
mm 1500 / 1650 2200 2550 2550/2670 2760 2845
mm 1500 / 1650 2400 2750 2750/2870 2960 3045
Dimensions of load
(L)
mm 1500 / 1650 2200 2200 2200 2200 2200
mm 1500 / 1650 2400 2400 2400 2400 2400
(M)
mm 1500 2200 / 2400 800 800 800 800
mm 1650 2200 / 2400 1000 1000 1000 1000
(N)
mm 1500 2200 / 2400
1200 1200 1200 1200
mm 1650 2200 / 2400
Technical specifications
Voltage Volt
220/240 1Ph 220/240 1Ph 220/240 1Ph 220/240 1Ph
220/240 3Ph 220/240 3Ph 220/240 3Ph 220/240 3Ph
380/415
3Ph+N
380/415
3Ph+N
380/415
3Ph+N
380/415
3Ph+N
