2.9. TECHNICAL SPOOL SPECIFICATIONS
Table rotational speed rpm 4÷10 4÷10 4÷10
Carriage up/down speed
m/
min.
1÷4 1÷4 1÷4
Total weigh kg 470÷555 485÷555 505÷585
Table 2.4: Technical machine specifications (Ecoplat TP FRD - TP RS - TP PPS)
Description
Unit of
meas-
ure
Ø C (L)
Model
Ecoplat TP FRD
Ecoplat TP FRD (for
net)
Ecoplat TP RS Ecoplat TP PPS
Table 2.5: Installed power (Ecoplat TP FRD - TP RS - TP PPS)
Rotating table spool carriage Pre-stretch motor.
Complete machi-
ne
ØC (mm) Capacity (kg) Output (Kw)
Type of reel
holding carriage
Output (Kw) Type Output (Kw) Output (Kw)
1500
1200 0,55 FRD/RS 0,18 - - 0,73
1200 0,55 FRD (for net) 0,37 - - 0,92
1200 0,55 PPS 0,37 PPS 0,18 1,10
1650
1200 0,75 FRD/RS 0,18 - - 0,93
1200 0,75 FRD (for net) 0,37 - - 1,12
1200 0,75 PPS 0,37 PPS 0,18 1,30
Table 2.6: Maximum capacity (Ecoplat TP FRD - TP RS - TP PPS)
Description
Unit of
measure
Model
Ecoplat TP FRD Ecoplat TP RS Ecoplat TP PPS
Max. load (Standard rotary table)
kg 1200 1200 1200
mm ØC=1500/1650 ØC=1500/1650 ØC=1500/1650
Table 2.7: Reel technical specifications
Description
Unit of
measure
Value
Film spool dimensions (A)
Max. external diameter
Type of reel holding carriage
(FRD)
mm 230
Type of reel holding carriage
(RS/PPS)
mm 300
Reel height mm 500
Film thickness µm 17÷35
Internal diameter mm 76
Max. weight kg 20
Net spool dimensions (B)
Max. external diameter mm 300
Reel height mm 500
Internal diameter mm 76
Max. weight kg 20
H
D
d
D
d
H
IDM-24153204400.pdf
A B
