CompactLogix 5370 Controllers Overview Chapter 1
Figure 2 shows an example EtherNet/IP system configuration for a
1769-L27ERM-QBFC1B controller.
Figure 2 - Example 1769-L27ERM-QBFC1B Control System Configuration on an
EtherNet/IP Network
Figure 3 shows an example EtherNet/IP system configuration for a
1769-L33ERM controller.
Figure 3 - Example 1769-L33ERM Control System Configuration on an EtherNet/IP Network
1769-L27ERM-QBFC1B
PanelView Plus 7
Stratix 5700
PowerFlex® 525
1734-AENTR POINT I/O
1794-AENTR FLEX I/O
Kinetix 5500
• 1769-AENTR
• 1769 Compact I/O
1769-L33ERM Control System
PanelView Plus 7
1794-AENTR FLEX I/O
Stratix 5700
1734-AENTR POINT I/O
Kinetix 5500
Kinetix 5500
• 1769-AENTR
• 1769 Compact I/O
