Rockwell Automation Publication 1769-UM021I-EN-P - May 2018 211
Use I/O Modules with CompactLogix 5370 L2 Controllers Chapter 8
Analog Input Data Format
Tab le 21 lists the bit value combinations you can use to select the output data
format for analog data that is sent to the controller for a channel.
You use bi ts
8…10 in words 3, 9, 15, and 21 to make this selection.
Analog Input Type and Operating Range
Tab le 22 lists the bit value combinations you can use to select the input type
and operating range for a channel.
You use bits 0…5 in words 3, 9, 15, 21, 29, and 37
to make the selections.
Table 21 - Analog Input Data Format
Analog Output Data Format
Bit Settings
(Words 3, 9, 15, and 21)
Bit 10 Bit 09 Bit 08
Raw/Proportional Data
000
Engineering Units 0 0 1
Engineering Units x 10 0 1 0
Scaled for PID 0 1 1
Percent Range 1 0 0
Spare
(1)
(1) An attempt to write a non-valid (any Spare value) bit configuration into the Input/Output Data Format Select field causes a
Module Configuration Error (contained in Mod_Condition Array). All bits shown as 0 in Table 2 1
are set to 0.
Values 5…7
Table 22 - Analog Input Type and Operating Range
Input Type and Normal
Operating Range
Bit Settings
(Words 3, 9, 15, and 21)
Bit 05 Bit 04 Bit 03 Bit 02 Bit Bit 00
-10
…10V DC 000000
0…5V DC 0 0 0 0 0 1
0…10V DC 0 0 0 0 1 0
4…20 mA 0 0 0 0 1 1
1…5V DC 0 0 0 1 0 0
0…20 mA 0 0 0 1 0 1
-50 mV…50 mv 0 0 0 1 1 0
-100…100 mV 0 0 0 1 1 1
Thermocouple J 001000
Thermocouple K 001001
Thermocouple T 001010
Thermocouple E 001011
Thermocouple R 001100
Thermocouple S 001101
Thermocouple B 001110
Thermocouple N 001111
