Rockwell Automation Publication 1769-UM021I-EN-P - May 2018 291

Develop Integrated Motion over an EtherNet/IP Network Application Chapter 11

6. If you must change the configuration for any of the following

parameters, click Change in the Module Definition area:

• Revision

•Electronic Keying

•Connection

•Power Structure

•Verify Power Rating on Connection

The Module dialog box appears.

7. Make the desired changes and click OK.

8. Click OK to create the drive in your project.

9. Add other components that your project requires.
