124 Rockwell Automation Publication 5069-UM003B-EN-P - January 2020
Appendix A Module Tags
Input Tags
Output Tags
Table 32 - DF1 Point to Point Input Tags
Name Data Type Definition Valid Values
Ix.DF1.RunMode BOOL Channel’s operating state 0 = Idle
•1 = Run
Ix.DF1.ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the module is not
connected, it changes the tag to 1.
0 = Connection running
1 = Connection not running
Ix.DF1.DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics threshold
is reached.
0 = No diagnostics active
1 = One or more diagnostics are active or the
prognostics threshold is reached
Ix.DF1.DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is detected,
and when a distinct diagnostic condition transitions from detected
to not detected.
Set to zero by product reset or power cycle. Wraps from 255 (-1) to 1
skipping zero.
-128…+127
The value of 0 is skipped except during module
power-up.
Ix.DF1.CTS BOOL Indicates whether the CTS is active. 0 = Inactive
•1 = Active
Ix.DF1.RTS BOOL Indicates whether the RTS is active. 0 = Inactive
•1 = Active
Ix.DF1.DSR BOOL Indicates whether the DSR is active. 0 = Inactive
•1 = Active
Ix.DF1.DCD BOOL Indicates whether the DCD is active. 0 = Inactive
•1 = Active
Ix.DF1.DTR BOOL Indicates whether the DTR is active. 0 = Inactive
•1 = Active
Ix.DF1.MsgProcessing BOOL Determine if instruction message is processing 0 = Not Processing
1 = Processing
Ix.DF1Modem.TxACK SINT Feedback from the latest Transmit Transaction ID. -128…+127
Ix.DF1Modem.RxlD SINT Notification of receiving by updating number. -128…+127
Ix.DF1Modem.RxDataLength INT Length of Produce Data of each channel. 1…128
Ix.DF1Modem.RxData[x] SINT (128) Received data from serial port. -128…+127
Table 33 - DF1 Point to Point Output Tags
Name Data Type Definition Valid Values
Ox.DF1Modem.TxID SINT This ID is incremented when you want to transmit data from the serial
port.
-128…+127
(1)
Ox.DF1Modem.DTR BOOL Signal level of DTR line sent out when rising edge of EXEC bit is detected. 0 = Inactive
•1 = Active
Ox.DF1Modem.RTS BOOL Signal level of the RTS line sent out when rising edge of EXEC bit is
detected.
•0 = Inactive
•1 = Active
Ox.DF1Modem.EXEC BOOL If EXEC bit changes 0 to 1, FW will output a signal level that is set in the
DTR/RTS tag.
•0 = Inactive
•1 = Active
Ox.DF1Modem.TxDataLength INT Length of Transmitted Data of each channel. 1…128
Ox.DF1Modem.TxData[x] SINT (128) Output data from module. -128…+127
(1) The value of 0 must be skipped except during module power-up.
